AlteSil™ Microbore Silicone Tubing

Manufactured from our high tear-strength peristaltic grade of silicone elastomer to precision tolerances of +/-0.05mm and consistant wall thickness making it ideal for use in: • Automated Analytical Chemistry • Dosing and Dispensing Systems • Peristaltic Pumps Supplied in coils of 15m.

Price (+VAT)

per Coil/15m

Select all options to see price

Product Code

116-R497-18

Availability

Select all options to see availability

Tensile Strength

9.5 Mpa (Standard AFNOR NF T 46- 002)

Tear Strength

38 kN/m (Standard ASTM D 624 A)

Hardness

50º Shore 'A' (Standard ASTM D 2240)

Density

1.13 g/cm³ (at 25ºC)

Elongation at Break

640% (Standard AFNOR NF T 46- 002)

Compression set

34% (22h/ 177°C/ 25%) (Standard ASTM D 395 B)

Temperature Range

-55ºC to 220ºC

Electrical

Generally to BS2848

Colour

Translucent

Cure Method

Peroxide

Material Grade

Food Contact and Biomedical

Drinking Water Contact Conformity

• Germany: KTZ regulation part 1.3.13.

Food Contact Conformity

• United States: US- FDA- CFR 21- part 177. 2600 • France: Journal Officiel – Brochure 1227– order dated 25 November 1992. • Germany: BGVV XVA and LIIA. • Italy: Gazetta Ufficiale – law dated 1973 and addendum.

Medical Conformity

Basic biological studies; cytotoxicity, irritation, sensitisation and hemocompatibility, required by directive 93/42 CE dated June 14 1993, relative to medical devices and USP Class VI of US, have been carried out on the cured raw material.

Disclaimer

In all cases it is the customer’s responsibility to verify conformity of the product with the tests imposed by the appropriate end-use regulations. All Altec products are supplied non-sterile for use in non-patient-connected applications.
